Corghi A2030HP Tilt-Back 26"-30" Tire Changer
In Stock SKU 0-11118134/00
OUR PRICE: $9,060.00
Regular Price: $9,519.00
Short Description
Corghi A2030HP Automatic Tilt-Back 26"-30" Tire Changer
The Corghi A2030HP Automatic Tilt-Back 26" - 30" Tire Changer is the strongest built, largest capacity, tilt-back rim clamp machine available. It handles wheels up to 26" and by adding a simple economical expansion kit, you can increase up to a 30" wheel. This machine also incorporates an ergonomic adjustable bead breaker shovel that allows you to adjust the shovel upward to be on the centerline of larger diameter wheels. This machine can truly cover with ease the widest range and combination of wheels and tires of any machine on the market. Like all Corghi machines, you get: Flexibility, Durability, and Reliability at the most competitive price.
All Corghi Rim Clamp Tire Changers Now Ship
Fully Assembled From The Warehouse
Description
Corghi A2030HP Automatic Tilt-Back 26"-30" Tire Changer
The Corghi A2030HP Automatic Tilt-Back 26" - 30" Tire Changer is the strongest built, largest capacity, tilt-back rim clamp machine available. It handles wheels up to 26" and by adding a simple economical expansion kit, you can increase up to a 30" wheel. This machine has also incorporates an ergonomic adjustable bead breaker shovel that allows you to adjust the shovel upward to be on the centerline of larger diameter wheels. This machine can truly cover with ease the widest range and combination of wheels and tires of any machine on the market. Like all Corghi machines you get: Flexibility, Durability, and Reliability at the most competitive price.
Corghi Rim Clamp Tire Changers Ship Fully Assembled
Starting 4/15/2026, all Corghi Rim Clamp Tire Changers will be shipped fully assembled from the warehouse. The objective of this initiative is to simplify installation, ensure consistent machine configuration, and allow customers to place their equipment into operation more quickly.
Key Advantage Of The Program Include:
- Fully Assembled Units - Each machine is assembled prior to shipment, ensuring consistent configuration and factory-level assembly.
- Faster Start-Up For The Shop - With no on-site assembly required, technicians simply connect the machine to air and power to begin operation.
- QR Code Video Support - Each machine includes access to unpacking and setup instructions via QR codes linking to step-by-step video guides.
- A QR Code will be attached to each machine with a link to an informational video on unpacking instructions for your Corghi Rim Clamp Tire Changer. The sentence below the QR Code provides instructions on how to switch the YouTube audio from English to Spanish.
- A QR Code will be attached to the top right of the tower of the machine with a link to a informational training video on the features and benefits of Corghi Rim Clamp Tire Changers.
See More Info section below for informational videos on Corghi Rim Clamp Tire Changer Functions, Features, and Helper Arms as well as a Corghi Rim Clamp Unpacking Video.
Features & Specs
Features
- Handles Wheels Up To 26"
- Optional Jaw Adapters Available To Change Up To 30"
- Has A Built-In Ergonomic Adjustable Bead Breaker Shovel That Lets You To Adjust The Shovel Upward To Be On The Centerline Of Larger Diameter Wheels
- This Machine Offers The Widest Range And Combination Of Wheels And Tires Of Any Machine On The Market
Specifications
- Turntable Standard 26" | 30" Upgrade Kit
- Internal Clamping Capacity: 13" - 29" | 13" - 29"
- External Clamping Capacity: 10" - 26" | 10" - 26"
- External Clamping With Jaws Adapters: 8" - 30" | 8" - 30"
- External Clamping Without Jaws Adapters: 3.5" - 14" | 3.5" - 14"
- External Clamping With Jaws Adapters: 3.5" - 12" | 3.5" - 12"
- Horizontal Arm Stroke: 8" - 26" | 12" - 30"
- Maximum Tire Diameter: 43"
- Maximum Tire Width: 14"
- Dv Version Rotation Torque: 958,83 lb-ft
- Dv Version Rotation Speed: 6 - 15 Rpm
- Height Above The Ground: 26.57"
- Bead Breaker
- Type: Adjustable Arm With Extending Shoe
- Maximum Opening: 14.9"
- Shoe Force: 15500 N
- Support: Telescopic
- Tool
- Working Range: 8" - 26"
- Column: Pneumatic Tilting
- Head Clamping: Pneumatic
- Power Supply
- Electrical 1Ph Dv Version: 115 V - 0.75 kW
- Operating Pressure: 145 psi
- Weight: 571 lbs.
- Warranty: (10) Years Transmission Parts, (3) Years Parts and (1) Year Labor
Corghi USA Limited Warranty Statement
General Terms
Corghi USA expressly warrants its products will be free from defects in material and/or workmanship for the time period specified. Corghi USA must be informed in writing within (7) days after discovery of a defect. Corghi USA reserves the right to repair or replace a product at our discretion. Consumable products and accessories such as but not limited to; plastic protection parts, bead breaker pads, inflation hoses, and rollers, are not covered under this warranty.
This warranty does not cover any damage resulting from abuse or failure to perform any necessary maintenance (i.e. damage due to or resulting from, faulty installation, neglect, misuse, improper electrical connections or electrical surges, problems resulting from excessive water, contaminated air system, or pollutant of any nature, fire or freight damage).
Corghi machines are warranted to be free of defects as follows:
Tire Changers:
A2030, A2024TI, 2024LL, A9824, A9824LL, A9830, A9222, Service Pro 124, Service Pro 324, BC200S, A2002 - (3) years parts and (1) year labor. Additional Transmission Warranty Models: A9222 - (5) years parts only. A2030, A2024TI, 2024LL, A9824, A9824LL, A9830 - (10) years parts only. AM50, AM500, AM5000, Master J, Master Code, Master28 - (3) years parts and (1) year labor. HD700, HD1300, HD1400, Monster TT, HD1800, Service Pro 440, Service Pro 426 - (3) years parts and (1) year labor. NOTE: Rubber pads, air lines, gauges, mount/demount heads, and swabs - (90) day warranty.
Wheel Balancers:
PL60, Service Pro 750, EM9250, EM9280, EM9580, EM9780, EM9980C, ET1450, ET88 - (3) years parts and (1) year labor.
Alignment Machines and Specialty Equipment:
(3) years parts and (1) year labor.
Disclaimer & Limitation on Liability
Accessories/Options
Corghi 8-11120032 Bead Press Tool Articulating Arm
OUR PRICE: $1,320.00
Regular Price: $1,389.00
More Information
Corghi A2030HP Tire Changer Brochure (.pdf)
Corghi A2030HP Tire Changer Manual (.pdf)
Corghi 2026 Customer Loyalty Program
When you purchase a Corghi machine between 1/1/26 and 12/31/26 you are qualified to enter the Customer Loyalty Program. After emailing or faxing the completed form below, you will receive a "Corghi Cash" coupon, good towards the purchase of a subsequent machine. This coupon is only valid for 6 months. The coupon value will be either 10% or 5% of the machine & associated accessories just purchased. This is based on the subtotal. Taxes, freight, and other charges are not included. The value is 10% if second machine goes to the same location or 5% if the machine is purchased for an alternative company owned location.
